TVM-144S : 144 x 144 Modular Matrix for main frame
Modular Matrix Switcher is a product that receives various interface video signals and selects and outputs high-definition digital images to multiple displays.

Max. Resolution 1920x1200 @60Hz
Max. Pixel Clock 165MHz
No Switching time (Real Seamless : 1㎲)
Slot Hot Swap
EDID Writing & HDCP
Variety in / out Slot
   - 3G-SDI, DVI, HDMI, VGA, Optic, HDBaseT
   - Quad Split Function (optional input slot)
Pattern Generator Function
Touch Screen Control
Redundant Power
TVM-144S : 144 x 144 Modular Matrix for main frame

Item

Specification

Minimum

Maximum

Power Power (DC) 110 V 240 V
Current 40 A 200 A
Redundant Power 480 W 2400 W
Temperature / Humidity Working Temperature 0 °C 60 °C
Storage Temperature -30 °C 70 °C
Working Humidity 0 %RH 85 %RH
Storage Humidity 0 %RH 95 %RH
Slot DVI 24 pin DVI-D male Connector
HDMI 19 pin HDMI Female Connector
VGA 15P D-Sub Female Connector
SDI BNC Connector
HDBaseT 8 pin RJ-45 female Connector
Optical Duplex LC Connector
Connect RS-232 9 pin D-Sub Connector
Ethernet 8 pin RJ-45 female Connector
USB USB A Type female Connector
Dimensions W444xD360xH298
