TVK-4000SH

4K Cross Converter

TVK-4000SH

Choice:

TVK-4000SH : 4K Cross Converter

12G SDI Input and Output
   - Support HD, 3G Level A/B, 6G, 12G
HDMI 2.0a Input and Output
   - Support up to 3840x2160@60p
Dual Scaler Included
   - Support SDI and HDMI outputs with independent resolutions
   - Convert resolutions and frame rates
Cross Conversion
   - SDI to HDMI, HDMI to SDI
LCD Preview and Touch Control
   - Monitor and control Inputs and Outputs settings
Firmware Update by USB Stick

TVK-4000SH : 4K Cross Converter

Item

Connector Type

Specifications

Q’ty

Input SDI BNC × 1 12G-SDI
HDMI A × 1 HDMI 2.0a
Output SDI BNC × 2 12G-SDI
SDI-Loop Out BNC × 1 12G-SDI
HDMI A × 1 HDMI 2.0a
UI LCD+Touch × 1 2.7” LCD + Capacitive Touch
Network Ethernet × 1
RJ45 × 1
10/100Mbps
Power DC-Jack × 1 12v / 3.5A
Resolutions   720p, 1080i, 1080p,2160p
Frame Rate   23.98, 24, 25, 29.97, 30, 50, 59.94, 60
Up / Down Scaling   Any Resolution -> Any Resolution
Frame Rate Conversion   Any Rate -> Any Rate
Firmware Upgrade   Yes Built-in Web Server using Ethernet
Preview Monitoring   Yes Front 2.7” LCD
Status Monitoring   Yes - Built-in Web Server
- Front LCD
Control   Yes - Built-in Web Server
- Front LCD GUI
- 9 x buttons

TVK-4000SH : 4K Cross Converter

  Manual   Download
  Installation   Download
  Total Brochure   Download
