F-10H : 10" HDR High Brightness Field Monitor
10” Full HD Field Monitor engineered for extreme outdoor environments.

10" HDR High Brightness Field Monitor
Featuring a 1400nit ultra-bright display and a strengthened glass front, the F-10H ensures exceptional visibility and protection in direct sunlight and challenging field conditions.
Its slim, lightweight aluminum body offers portability without compromising durability.
Equipped with advanced tools like 3D LUT import, HDR, ARRI metadata display, Horizontal Level Meter, and precise waveform monitoring, the F-10H is designed to meet the demands of professional cinematographers, DPs, and field crews in any shooting scenario.
Main Body Dimensions
Main Body 258 x 154 x 29.8(mm) / 10.15 x 6.06 x 1.17(inch)
Weight 1.2kg / 2.65lbs
Product Highlights
• 10”, Full HD Resolution (1920×1200)
• Max Luminance 1400nits
• DCI-P3 Coverage 95%
• Tempered Glass Treatment
• HDR (PQ / HLG / Slog3)
• Camera LUTs (Log-C, C-Log, S-Log1/2/3, Red Gamma3/4)
• Custom 3D-LUT Import
• Sharpness + Peaking Boost
• ARRI Metadata Display
• Scan / Anamorphic Desqueeze / Zoom / Split Zoom
• 3x 3G SDI (1x 3G SDI Selectable I/O)
• HDMI 2.0 ↔ SDI Cross Conversion
• Luma(Y') Zone Check (Zebra / Color)
• H/V Flip, Auto Flip
• Horizontal Meter
• Waveform / Vectorscope
• DC 12V ~ 34V
